Junior mid size

All kilns

Mid-version of the Junior pallet kiln series are normally used when there are space restrictions.

This unit can load 420 GMA pallets.

Standard components

› three main fans (2HP each)
› direct gas heating (850000 btu/hr)
› inside aluminum sheeting
› single power exhaust venting (2HP)
› rear side access door
› computerized controls
› redundant wood temp system
› wireless communication of office for record keeping

Available upgrades

› stainless steel sheeting inside
› double power exhaust venting
› heat recovery on venting (saves gas)
› dual heat system controls
› hot water heating coils
› steam heating coils
› rear side access door


› outside length: 40ft
› outside width: 12ft
› outside height: 12ft 6in

› loading depth: 30ft
› loading width: 11ft 3in
› loading height: 9ft 2in
